SISTEMA RADIANTE PAVIMENTO





                                           COLLETTORI PREMONTATI - BASIC




                                                                    G1


                                                                  I                             H        H1


                                                                   G1
                                                                              C      G

                                                                                  L                 L1

       Collettori  premontati  in  tecnopolimero.  Forniti  completi  di:  flussometri  con  funzione  di  detentore  ed  indicatore  di  flusso,  valvole
       termostatizzabili con volantino manuale, termometro a contatto, gruppi terminali di scarico manuale aria/ acqua 1”, coppia di staffe di
       fissaggio in tecnopolimero. Temperatura di esercizio: 4÷70 °C . Pressione max di esercizio: 6 bar

                 NUMERO                          I         L         L1        C         H        H1
       CODICE    STACCHI     G1        G2       mm        mm        mm        mm        mm        mm         €
       0078969    2 + 2      1”      3/4” EK    200       195        73        50       365       298      225,000

       0078970 ●  3 + 3      1”      3/4” EK    200       240        73        50       365       298      268,000
       0078971 ●  4 + 4      1”      3/4” EK    200       285        73        50       365       298      318,000
       0078972 ●  5 + 5      1”      3/4” EK    200       330        73        50       365       298      372,000
       0078973 ●  6 + 6      1”      3/4” EK    200       375        73        50       365       298      432,000
       0078974 ●  7 + 7      1”      3/4” EK    200       420        73        50       365       298      479,000
       0078975 ●  8 + 8      1”      3/4” EK    200       465        73        50       365       298      536,000
       0078976 ●  9 + 9      1”      3/4” EK    200       510        73        50       365       298      591,000
       0078977 ●  10 + 10    1”      3/4” EK    200       555        73        50       365       298      648,000
       0078978 ●  11 + 11    1”      3/4” EK    200       600        73        50       365       298      706,000
       0078979 ●  12 + 12    1”      3/4” EK    215       645        73       50        365       298      758,000
       0078508    6 + 6     1” 1/4   3/4” EK    215       370        95       50        395       330      583,000
       0078509    7 + 7     1” 1/4   3/4” EK    215       415        95       50        395       330      657,000
       0078510    8 + 8     1” 1/4   3/4” EK    215       460        95       50        395       330      728,000
       0078511    9 + 9     1” 1/4   3/4” EK    215       505        95       50        395       330      807,000
       0029214    10 + 10   1” 1/4   3/4” EK    215       550        95       50        395       330      881,000
       0078241    11 + 11   1” 1/4   3/4” EK    215       595        95       50        395       330      957,000
       0029216    12 + 12   1” 1/4   3/4” EK    215       640        95       50        395       330     1.034,000
       0078980 ●  13 + 13   1” 1/4   3/4” EK    215       685        95       50        395       330     1.108,000
       0078981 ●  14 + 14   1” 1/4   3/4” EK    215       730        95       50        395       330     1.182,000
       0078982    15 +15    1” 1/4   3/4” EK    215       775        95       50        395       330     1.264,000

       0078983 ●  16 + 16   1” 1/4   3/4” EK    215       820        95       50        395       330     1.343,000












            20                Per tutte le schede tecniche e dichiarazioni di conformità: www.divisionenergy.com/prodotti/
